| Series | 95 |
| Operating principle | Reflection principle |
| Application | Detection of highly transparent bottles Detection of highly transparent films and glass panes |
Special version
| Special version | Autocollimation |
Optical data
| Operating range | 0 ... 1.8 m |
| Operating range limit | 0 ... 3 m |
| Light source | LED, Red |
Electrical data
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance data
| Supply voltage UB | 10 ... 30 V, DC |
| Residual ripple | 0 ... 15 %, From UB |
| Open-circuit current | 0 ... 35 mA |
Outputs
| Number of digital switching outputs | 2 Piece(s) |
Switching output 1
| Switching element | Transistor, PNP |
| Switching principle | Light switching |
Switching output 2
| Switching element | Transistor, PNP |
| Switching principle | Dark switching |
Time behavior
| Switching frequency | 1,000 Hz |
| Response time | 0.5 ms |
Connection
Connection 1
| Type of connection | Connector |
| Thread size | M12 |
| Material | Stainless steel |
| No. of pins | 4 -pin |
Mechanical data
| Dimension (W x H x L) | 17 mm x 66 mm x 35 mm |
| Housing material | Metal |
| Metal housing | Zinc |
| Lens cover material | Glass |
| Net weight | 90 g |
| Type of fastening | Through-hole mounting |
Operation and display
| Operational controls | Multiturn potentiometer |
Environmental data
| Ambient temperature, operation | -25 ... 60 °C |
Certifications
| Degree of protection | IP 67 |
| Protection class | II |
| Standards applied | IEC 60947-5-2 |
